Commodity details
- Product name：Mini UHF Bulkhead Connector Angled Jack for Panel Mount
- product number：EB-009-0013
- Shop：BEEelec Official Store
- weight：0gram
- Shelf time:2020-12-24 17:48:57
Features:
- Pcb Mount, Jack/female, Angled/90～, bulkhead, Mini UHF;
- Miniature version of UHF connectors with lightweight and higher cost-effective;
- 3/8-24 threaded coupling with excellent application frequency up to 2.5GHz.?
- High Quality with 30 days 100% Money back;
- From the OEM Original Factory, same quality with much better price.
Main Application of Mini UHF?Connectors:
Antennas, Cable Modems, PC/LAN
Techinial Datasheet:
Electrical Characteristics
- Impedanceㄩ50 ohm
- Frequency Range: 0~2GHz
- Vlotage Rating: 335 volts
- Dielectric Withstanding Voltage: 1000VRMS
- VSWR: 1.25 max
- Insulation Resistance: 沖 5000M次
Mechanical Characteristics
- Coupling: 3/8-24 threaded coupling
- Cable Affixment(Braid or Center Contact): Crimp
- Cable Retention: 沖 40 lb
Environmental Characteristics
- Temprature Range: -55～C ~ +85～C
- Shock: Mil-STD-202
- Vibration: Mil-STD-202
- Thermal Shock: Mil-STD-202
- Salt Spray: Mil-STD-202
